Product features
1. Basic model, ordinary type control box, simple operation, easy to master.
2. The asphalt temperature and the speed of the asphalt pump are digitally displayed, making it clear at a glance.
3. Equipped with a reducer, the vehicle speed slows down, making it suitable for manual spraying.
4. High-torque hydraulic motor, solving the problem of difficult starting.
5. A unique gas path cleaning system solves the problem of residual asphalt clogging after construction.
6. Fully automatic burner, automatic ignition, automatic flameout in case of fault protection, with good reliability.
7. On-board diesel generator provides power guarantee, and heating does not require starting the vehicle.
Keywords：
quot,8-direction,General,Guide
Categores：
Ordinary type asphalt spreader
Product Enquiries：
+86-17705341945Product description
Configuration table of 8-cubic-meter standard asphalt Spreader
Asphalt tank | SPT16.34 | Self-made | Volume8m3 |
Thickness of the insulation layer | 50mm | Aluminum silicate | |
Heating flue | One | Heating system | |
Hydraulic system | Racle | Everson | Taiwan |
Cold oil cooler | AH1470 | Wuxi Yuda | |
Control system | Xr110 | Self-made | Cab control |
Spray pipe | 6m/40 Nozzle | Self-made | Common type nozzle (copper nozzle) |
Spraying form | Sector surface | ||
Asphalt pump | KCB633 | Hengsheng | 633L/min |
Generator | CC3500E | Chang Chai | 3.0kw |
Burner | G20 | Riyadh Road | 20×104 car L/h，Italy |
Power take-off | Chassis configuration | ||
Hydraulic pump | CBHZ-F563-ALPL | Hefei Changyuan | Hefei, Anhui |
Hydraulic motor | AKS05-110B | Taylorms | Ningbo, Zhejiang |
Valve | Manual butterfly valveDN65 | Jiangsu Beifa Technology | Wuxi, Jiangsu |
Manual butterfly valveDN65 | Jiangsu Beifa Technology | Wuxi, Jiangsu | |
Valve | SC100×250 | Adek | Ningbo |
Sprinkling width | 4.5meter | ||
Sprinkling amount | 0.2-3kg/m2 | ||
Cleaning method | Diesel + high-pressure air |
Product features
1. Basic model, ordinary type control box, simple operation, easy to master.
2. The asphalt temperature and the speed of the asphalt pump are digitally displayed, making it clear at a glance.
3. Equipped with a reducer, the vehicle speed slows down, making it suitable for manual spraying.
4. High-torque hydraulic motor, solving the problem of difficult starting.
5. A unique gas path cleaning system solves the problem of residual asphalt clogging after construction.
6. Fully automatic burner, automatic ignition, automatic flameout in case of fault protection, with good reliability.
7. On-board diesel generator provides power guarantee, and heating does not require starting the vehicle.
