Electrically heated vertical asphalt tank
1. Integrated design, small size and easy installation
2. Electric heating, large heat exchange area, preventing dry burning
3. Linear output, safe and reliable
4. Automatic temperature control, fast heating, and precise temperature measurement
5. The design is mature to prevent coking and overheating from damaging the asphalt
6. Multiple tanks can be centrally controlled
Keywords：
Electrically heated vertical a
Categores：
Electrically heated vertical asphalt tank
Product Enquiries：
+86-17705341945Product description
Electronic control system
1. The plc, modules, low-voltage electrical appliances and main component electrical appliances all adopt Siemens
2. Electrical control cabinet, electroplated and powder-coated outdoor three-proof electrical cabinet
3. The system includes a set of intelligent electric heating asphalt tank control system
System composition: It includes plc and modules, heating devices, wireless network modules, fault feedback modules, pressure sensors, liquid level sensors, buzzers, intelligent display instruments, temperature sensors, agitators and electric valves. All the heating devices are connected to the plc
4. The control system adopts dual display and operation of industrial touch screen and industrial computer, and can operate independently
5. Timed on/off function, which can be set to turn on/off within 1 to 24 hours
6. Power-off memory function, which can remember the on/off status and the modified operating parameters of the heater
7. All temperature sensors have real-time temperature display and alarm functions
8. The system is equipped with a self-checking function, which can automatically detect the working conditions of each part and take corresponding actions
9. You can make any reservation and set the heating power and heating time at different times
10. The system can be networked to manage multiple asphalt tanks locally or remotely. Communication modules can also be added to display the working status and alarm status of the asphalt tanks via text messages and wechat
The control system can increase or decrease the number of managed asphalt tanks by adding or reducing the number of modules, with a maximum support of 128 asphalt tanks
12. The asphalt tank equipment agitator supports manual and scheduled operation temperature and time, and is equipped with low-temperature, overload protection and alarm functions
13. The asphalt tank is equipped with liquid level and weight display, and supports low liquid level alarm and dry burning protection functions
14. The exhaust pipe is heated and insulated by heat transfer oil, and is equipped with exhaust pipe temperature monitoring and electric heating tube start-up protection functions
